Toshiba Semiconductor and Storage TPN1600ANH,L1Q

Part No.:: TPN1600ANH,L1Q

Manufacturer:: Toshiba Semiconductor and Storage

Package:: 8-TSON Advance (3.1x3.1)

Datasheet:: TPN1600ANH,L1Q.pdf

Description:: MOSFET N CH 100V 17A 8TSON-ADV

In Stock:: 3067

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TPN1600ANH,L1Q Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
U-MOSVIII-H
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
100 V
Current-ContinuousDrain(Id)@25°C:
17A (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
10V
RdsOn(Max)@IdVgs:
16mOhm @ 8.5A, 10V
Vgs(th)(Max)@Id:
4V @ 200µA
GateCharge(Qg)(Max)@Vgs:
19 nC @ 10 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
1600 pF @ 50 V
FETFeature:
-
PowerDissipation(Max):
700mW (Ta), 42W (Tc)
OperatingTemperature:
150°C (TJ)
MountingType:
Surface Mount
