Toshiba Semiconductor and Storage TPH1R306PL,L1Q

Part No.:: TPH1R306PL,L1Q

Manufacturer:: Toshiba Semiconductor and Storage

Package:: 8-SOP Advance (5x5)

Datasheet:: TPH1R306PL,L1Q.pdf

Description:: MOSFET N-CH 60V 100A 8SOP

In Stock:: 2371

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TPH1R306PL,L1Q Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
U-MOSIX-H
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
60 V
Current-ContinuousDrain(Id)@25°C:
100A (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
4.5V, 10V
RdsOn(Max)@IdVgs:
1.34mOhm @ 50A, 10V
Vgs(th)(Max)@Id:
2.5V @ 1mA
GateCharge(Qg)(Max)@Vgs:
91 nC @ 10 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
8100 pF @ 30 V
FETFeature:
-
PowerDissipation(Max):
960mW (Ta), 170W (Tc)
OperatingTemperature:
175°C
MountingType:
Surface Mount
