ON Semiconductor SVD2955T4G

Part No.:: SVD2955T4G

Manufacturer:: ON Semiconductor

Package:: DPAK

Datasheet:: SVD2955T4G.pdf

Description:: MOSFET P-CH 60V 12A DPAK

In Stock:: 2610

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SVD2955T4G Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Automotive, AEC-Q101
ProductStatus:
Active
FETType:
P-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
60 V
Current-ContinuousDrain(Id)@25°C:
12A (Ta)
DriveVoltage(MaxRdsOnMinRdsOn):
10V
RdsOn(Max)@IdVgs:
180mOhm @ 6A, 10V
Vgs(th)(Max)@Id:
4V @ 250µA
GateCharge(Qg)(Max)@Vgs:
30 nC @ 10 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
750 pF @ 25 V
FETFeature:
-
PowerDissipation(Max):
55W (Tj)
OperatingTemperature:
-55°C ~ 175°C (TJ)
MountingType:
Surface Mount
