Vishay Siliconix SUM110P06-07L-E3

Part No.:: SUM110P06-07L-E3

Manufacturer:: Vishay Siliconix

Package:: TO-263 (D²Pak)

Datasheet:: SUM110P06-07L-E3.pdf

Description:: MOSFET P-CH 60V 110A TO263

In Stock:: 2414

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SUM110P06-07L-E3 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
TrenchFET®
ProductStatus:
Active
FETType:
P-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
60 V
Current-ContinuousDrain(Id)@25°C:
110A (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
4.5V, 10V
RdsOn(Max)@IdVgs:
6.9mOhm @ 30A, 10V
Vgs(th)(Max)@Id:
3V @ 250µA
GateCharge(Qg)(Max)@Vgs:
345 nC @ 10 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
11400 pF @ 25 V
FETFeature:
-
PowerDissipation(Max):
3.75W (Ta), 375W (Tc)
OperatingTemperature:
-55°C ~ 175°C (TJ)
MountingType:
Surface Mount
