Name: STP75NF75
Brand: STMicroelectronics
SKU: STP75NF75
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

STMicroelectronics STP75NF75

Part No.:: STP75NF75

Manufacturer:: STMicroelectronics

Package:: TO-220

Datasheet:: STP75NF75.pdf

Description:: MOSFET N-CH 75V 80A TO220AB

In Stock:: 3514

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

STP75NF75 Specifications

Packaging:
Tube
Series:
STripFET™ II
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
75 V
Current-ContinuousDrain(Id)@25°C:
80A (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
10V
RdsOn(Max)@IdVgs:
11mOhm @ 40A, 10V
Vgs(th)(Max)@Id:
4V @ 250µA
GateCharge(Qg)(Max)@Vgs:
160 nC @ 10 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
3700 pF @ 25 V
FETFeature:
-
PowerDissipation(Max):
300W (Tc)
OperatingTemperature:
-55°C ~ 175°C (TJ)
MountingType:
Through Hole
