STMicroelectronics STN1NK60ZL

Part No.:: STN1NK60ZL

Manufacturer:: STMicroelectronics

Package:: SOT-223

Datasheet:: STN1NK60ZL.pdf

Description:: MOSFET N-CH 600V 300MA SOT223

In Stock:: 3340

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

STN1NK60ZL Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
SuperMESH™
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
600 V
Current-ContinuousDrain(Id)@25°C:
300mA (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
10V
RdsOn(Max)@IdVgs:
15Ohm @ 400mA, 10V
Vgs(th)(Max)@Id:
4.5V @ 50µA
GateCharge(Qg)(Max)@Vgs:
6.9 nC @ 10 V
Vgs(Max):
±30V
InputCapacitance(Ciss)(Max)@Vds:
94 pF @ 25 V
FETFeature:
-
PowerDissipation(Max):
3.3W (Tc)
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
