STMicroelectronics STB18NM80

Part No.:: STB18NM80

Manufacturer:: STMicroelectronics

Package:: D²PAK (TO-263)

Datasheet:: STB18NM80.pdf

Description:: MOSFET N-CH 800V 17A D2PAK

In Stock:: 2996

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

STB18NM80 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
MDmesh™
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
800 V
Current-ContinuousDrain(Id)@25°C:
17A (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
10V
RdsOn(Max)@IdVgs:
295mOhm @ 8.5A, 10V
Vgs(th)(Max)@Id:
5V @ 250µA
GateCharge(Qg)(Max)@Vgs:
70 nC @ 10 V
Vgs(Max):
±25V
InputCapacitance(Ciss)(Max)@Vds:
2070 pF @ 50 V
FETFeature:
-
PowerDissipation(Max):
190W (Tc)
OperatingTemperature:
150°C (TJ)
MountingType:
Surface Mount
