Vishay Siliconix SQJ431AEP-T1_GE3

Part No.:: SQJ431AEP-T1_GE3

Manufacturer:: Vishay Siliconix

Package:: PowerPAK® SO-8

Datasheet:: SQJ431AEP-T1_GE3.pdf

Description:: MOSFET P-CH 200V 9.4A PPAK SO-8

In Stock:: 2105

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SQJ431AEP-T1_GE3 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Automotive, AEC-Q101, TrenchFET®
ProductStatus:
Active
FETType:
P-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
200 V
Current-ContinuousDrain(Id)@25°C:
9.4A (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
6V, 10V
RdsOn(Max)@IdVgs:
305mOhm @ 3.8A, 10V
Vgs(th)(Max)@Id:
3.5V @ 250µA
GateCharge(Qg)(Max)@Vgs:
85 nC @ 10 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
3700 pF @ 25 V
FETFeature:
-
PowerDissipation(Max):
68W (Tc)
OperatingTemperature:
-55°C ~ 175°C (TJ)
MountingType:
Surface Mount
