STMicroelectronics SCTW100N65G2AG

Part No.:: SCTW100N65G2AG

Manufacturer:: STMicroelectronics

Package:: HiP247™

Datasheet:: SCTW100N65G2AG.pdf

Description:: SICFET N-CH 650V 100A HIP247

In Stock:: 2139

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SCTW100N65G2AG Specifications

Packaging:
Tube
Series:
Automotive, AEC-Q101
ProductStatus:
Active
FETType:
N-Channel
Technology:
SiCFET (Silicon Carbide)
DraintoSourceVoltage(Vdss):
650 V
Current-ContinuousDrain(Id)@25°C:
100A (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
18V
RdsOn(Max)@IdVgs:
26mOhm @ 50A, 18V
Vgs(th)(Max)@Id:
5V @ 5mA
GateCharge(Qg)(Max)@Vgs:
162 nC @ 18 V
Vgs(Max):
+22V, -10V
InputCapacitance(Ciss)(Max)@Vds:
3315 pF @ 520 V
FETFeature:
-
PowerDissipation(Max):
420W (Tc)
OperatingTemperature:
-55°C ~ 200°C (TJ)
MountingType:
Through Hole
