Name: NVTFS5826NLWFTAG
Brand: onsemi
SKU: NVTFS5826NLWFTAG
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

onsemi NVTFS5826NLWFTAG

Part No.:: NVTFS5826NLWFTAG

Manufacturer:: onsemi

Package:: 8-WDFN (3.3x3.3)

Datasheet:: NVTFS5826NLWFTAG.pdf

Description:: MOSFET N-CH 60V 7.6A 8WDFN

In Stock:: 2089

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

NVTFS5826NLWFTAG Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Automotive, AEC-Q101
ProductStatus:
Obsolete
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
60 V
Current-ContinuousDrain(Id)@25°C:
7.6A (Ta)
DriveVoltage(MaxRdsOnMinRdsOn):
4.5V, 10V
RdsOn(Max)@IdVgs:
24mOhm @ 10A, 10V
Vgs(th)(Max)@Id:
2.5V @ 250µA
GateCharge(Qg)(Max)@Vgs:
16 nC @ 10 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
850 pF @ 25 V
FETFeature:
-
PowerDissipation(Max):
3.2W (Ta), 22W (Tc)
OperatingTemperature:
-55°C ~ 175°C (TJ)
MountingType:
Surface Mount

NVTFS5826NLWFTAG this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including NVTFS5826NLWFTAG price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for NVTFS5826NLWFTAG to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

NVTFS5826NLWFTAG information

Views：

NVTFS5826NLWFTAG Typical application Circuitry

NVTFS5826NLWFTAG

The NVTFS5826NLWFTAG is a power MOSFET, specifically a N-channel, enhancement-mode field-effect transistor (FET) known for its high efficiency and low on-resistance. It's typically used in power management applications such as DC/DC converters, motor drives, and battery management systems due to its ability to handle high currents and switch efficiently.

Let's explore its application in a DC/DC converter circuit, where the NVTFS5826NLWFTAG is used as the main switching element.

Designing a DC/DC Converter with NVTFS5826NLWFTAG:

1. Power Supply Connection: Connect the source pin (pin 3) of the NVTFS5826NLWFTAG to the ground of the power supply. The drain pin (pin 1) should be connected to the negative side of the inductor, forming the main current path of the converter.

2. Gate Drive Circuit: The gate pin (pin 4) of the NVTFS5826NLWFTAG controls its on/off state. Connect this pin to a gate driver circuit, ensuring that the driver can supply the necessary voltage and current to switch the NVTFS5826NLWFTAG efficiently.

3. Feedback and Control: Implement a feedback mechanism to control the output voltage of the DC/DC converter. Use a voltage divider to sense the output voltage and connect it to a PWM controller. The PWM controller adjusts the duty cycle of the gate drive signal to regulate the output voltage.

4. Snubber Circuit: Add a snubber circuit across the drain and source of the NVTFS5826NLWFTAG to protect it from voltage spikes caused by the inductive load. This usually involves a series resistor and capacitor.

5. Decoupling Capacitors: Place decoupling capacitors close to the NVTFS5826NLWFTAG to stabilize the local voltage supply and reduce noise, especially during the high-speed switching.

6. Thermal Management: The NVTFS5826NLWFTAG can generate significant heat at high currents. Ensure proper thermal management by providing a heatsink or designing a PCB with adequate thermal dissipation capabilities.

Key Design Considerations:

- Gate Drive Requirements: Ensure that the gate drive circuit can provide the appropriate voltage and current to fully turn on the NVTFS5826NLWFTAG, minimizing conduction losses.

- Switching Frequency: Choose an optimal switching frequency for the DC/DC converter. Higher frequencies allow for smaller passive components but increase switching losses.

- Parasitic Inductance: Minimize the parasitic inductance in the current path to reduce voltage spikes during switching.

- Load Characteristics: Understand the characteristics of the load connected to the DC/DC converter. Ensure that the NVTFS5826NLWFTAG can handle the maximum load current without exceeding its maximum temperature.

- Protection Features: Implement protection features such as over-current protection, over-voltage protection, and thermal shutdown to ensure the longevity of the NVTFS5826NLWFTAG and the safety of the entire system.

In summary, the NVTFS5826NLWFTAG is an efficient and reliable component for high-power applications like DC/DC converters. When designing circuits with the NVTFS5826NLWFTAG, attention to gate drive configuration, switching frequency, thermal management, and protection mechanisms is crucial to create a stable, efficient, and safe system.
