ON Semiconductor NVMFS5C460NLWFAFT1G

Part No.:: NVMFS5C460NLWFAFT1G

Manufacturer:: ON Semiconductor

Package:: 5-DFN (5x6) (8-SOFL)

Datasheet:: NVMFS5C460NLWFAFT1G.pdf

Description:: MOSFET N-CH 40V 21A/78A 5DFN

In Stock:: 3016

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

NVMFS5C460NLWFAFT1G Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
Automotive, AEC-Q101
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
40 V
Current-ContinuousDrain(Id)@25°C:
21A (Ta), 78A (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
4.5V, 10V
RdsOn(Max)@IdVgs:
4.5mOhm @ 35A, 10V
Vgs(th)(Max)@Id:
2V @ 250µA
GateCharge(Qg)(Max)@Vgs:
23 nC @ 10 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
1300 pF @ 25 V
FETFeature:
-
PowerDissipation(Max):
3.6W (Ta), 50W (Tc)
OperatingTemperature:
-55°C ~ 175°C (TJ)
MountingType:
Surface Mount

NVMFS5C460NLWFAFT1G this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including NVMFS5C460NLWFAFT1G price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for NVMFS5C460NLWFAFT1G to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

NVMFS5C460NLWFAFT1G information

Views：

NVMFS5C460NLWFAFT1G Typical application Circuitry

NVMFS5C460NLWFAFT1G is an N-Channel Power MOSFET developed by ON Semiconductor. It enables effective power control in a number of applications as an electrical component.

Its versatility makes the NVMFS5C460NLWFAFT1G suitable for a broad range of applications, including power supply circuitry, motor control, load switching, and DC-DC converters.

The NVMFS5C460NLWFAFT1G possesses several distinct characteristics:

- Drain-Source Voltage (Vdss): 40V

- Continuous Drain Current (Id): 37A at 25°C

- Maximum Power Dissipation: 50W at 25°C

- Low Gate Charge (Qg) facilitating fast switching

- Low RDS(on) reducing on-state losses

- These features contribute to the device's efficiency, particularly in high-frequency switching applications.

Let's consider using the NVMFS5C460NLWFAFT1G in a DC-DC converter application:

1. Source Pin (Pin 5): In most circuits, the Source pin is connected to the ground. In a DC-DC converter, this pin will be tied to the system ground.

2. Gate Pin (Pin 4): The MOSFET's switching is controlled by the Gate pin. In a DC-DC converter, it will receive the switching signal from the control circuitry.

3. Drain Pin (Pin 2): This pin will connect to the higher voltage level or load. In a DC-DC converter, it will be connected to the switching node of the converter, which is the connection point of the inductor, capacitor, and the MOSFET itself.

When incorporating the NVMFS5C460NLWFAFT1G into a design, it is essential to consider:

- Heat Dissipation: As this device can handle high power, appropriate measures must be taken to prevent overheating. The use of heatsinks or fans can assist in this respect.

- Overvoltage Protection: Implementing flyback diodes or other protective measures can help to prevent damage from high voltage or current spikes.

- Drive Circuitry: Proper gate driving circuitry is necessary to ensure safe and efficient operation of the NVMFS5C460NLWFAFT1G.

- PCB Design: The PCB layout should minimize stray inductances and resistances, while also facilitating efficient heat dissipation.

In conclusion, the NVMFS5C460NLWFAFT1G is a highly capable N-Channel Power MOSFET that can play a significant role in a multitude of power management applications.
