ON Semiconductor NTS4001NT1G

Part No.:: NTS4001NT1G

Manufacturer:: ON Semiconductor

Package:: SC-70-3 (SOT323)

Datasheet:: NTS4001NT1G.pdf

Description:: MOSFET N-CH 30V 270MA SC70-3

In Stock:: 3435

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

NTS4001NT1G Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
-
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
30 V
Current-ContinuousDrain(Id)@25°C:
270mA (Ta)
DriveVoltage(MaxRdsOnMinRdsOn):
2.5V, 4V
RdsOn(Max)@IdVgs:
1.5Ohm @ 10mA, 4V
Vgs(th)(Max)@Id:
1.5V @ 100µA
GateCharge(Qg)(Max)@Vgs:
1.3 nC @ 5 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
33 pF @ 5 V
FETFeature:
-
PowerDissipation(Max):
330mW (Ta)
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
