ON Semiconductor NTR5198NLT1G

Part No.:: NTR5198NLT1G

Manufacturer:: ON Semiconductor

Package:: SOT-23-3 (TO-236)

Datasheet:: NTR5198NLT1G.pdf

Description:: MOSFET N-CH 60V 1.7A SOT23-3

In Stock:: 3432

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

NTR5198NLT1G Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
-
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
60 V
Current-ContinuousDrain(Id)@25°C:
1.7A (Ta)
DriveVoltage(MaxRdsOnMinRdsOn):
4.5V, 10V
RdsOn(Max)@IdVgs:
155mOhm @ 1A, 10V
Vgs(th)(Max)@Id:
2.5V @ 250µA
GateCharge(Qg)(Max)@Vgs:
2.8 nC @ 4.5 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
182 pF @ 25 V
FETFeature:
-
PowerDissipation(Max):
900mW (Ta)
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount

NTR5198NLT1G this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including NTR5198NLT1G price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for NTR5198NLT1G to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

NTR5198NLT1G information

Views：

NTR5198NLT1G Typical application Circuitry

NTR5198NLT1G

The NTR5198NLT1G is a P-channel Power MOSFET, known for its low on-resistance and high efficiency in power switching applications. It's commonly used in power management applications such as load switches, battery management systems, and DC/DC converters due to its ability to handle moderate power levels and switch efficiently.

Let's examine how it might be utilized in a battery management system, where the battery's charging and discharging are managed by the NTR5198NLT1G.

Designing a Battery Management System with NTR5198NLT1G:

1. Power Source Connection: Connect the source pin (pin 3) of the NTR5198NLT1G to the positive terminal of the battery. The NTR5198NLT1G will be able to regulate the connection between the battery and the remainder of the system with this arrangement.

2. Load Connection: Connect the drain pin (pin 2) of the NTR5198NLT1G to the load or the charging circuit. This pin will carry the current from the battery to the load or from the charging source to the battery.

3. Gate Drive Circuit: The gate pin (pin 1) of the NTR5198NLT1G controls its on/off state. Connect this pin to a gate driver circuit, ensuring that the driver can provide the necessary voltage to switch the NTR5198NLT1G efficiently. Remember, for P-channel MOSFETs, applying a voltage lower than the source voltage turns the device on.

4. Current Sensing: Implement a current sensing mechanism to monitor the charging and discharging current of the battery. This can involve a low-value resistor in series with the NTR5198NLT1G and measuring the voltage across it.

5. Voltage Regulation: Ensure the charging voltage is regulated and does not exceed the battery's maximum voltage. This may involve a voltage regulator or a feedback mechanism to the gate driver controlling the NTR5198NLT1G.

6. Thermal Management: The NTR5198NLT1G can generate heat during high current operations. Ensure proper thermal management by using a heatsink or designing a PCB with good thermal dissipation properties.

7. Protection Circuits: Integrate protection circuits such as over-voltage, over-current, and under-voltage lockout to safeguard the battery and the system. This ensures the NTR5198NLT1G operates within safe parameters.

Key Design Considerations:

- Gate Drive Requirements: Ensure the gate drive circuit can provide the appropriate voltage to fully turn on the NTR5198NLT1G, minimizing conduction losses.

- Switching Characteristics: Understand the switching speed and gate charge characteristics of the NTR5198NLT1G to optimize the efficiency of the charging/discharging circuit.

- Thermal Performance: Manage the thermal performance of the NTR5198NLT1G, especially if the battery management system handles high currents or operates in a high-temperature environment.

- Protection Mechanisms: Implement robust protection mechanisms to prevent damage to the battery, the NTR5198NLT1G, and the connected load due to abnormal conditions.

- Current Sensing Accuracy: Ensure accurate current sensing for effective monitoring and control of the charging/discharging process.

In conclusion, the NTR5198NLT1G is an effective and reliable component for power management applications like battery management systems. When designing circuits with the NTR5198NLT1G, careful attention to gate drive configuration, thermal management, protection circuits, and accurate sensing mechanisms is essential to create a stable, efficient, and safe system.
