ON Semiconductor NTR4171PT1G

Part No.:: NTR4171PT1G

Manufacturer:: ON Semiconductor

Package:: SOT-23-3 (TO-236)

Datasheet:: NTR4171PT1G.pdf

Description:: MOSFET P-CH 30V 2.2A SOT23-3

In Stock:: 9000

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

NTR4171PT1G Specifications

Packaging:
Tape & Reel (TR),Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
-
ProductStatus:
Active
FETType:
P-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
30 V
Current-ContinuousDrain(Id)@25°C:
2.2A (Ta)
DriveVoltage(MaxRdsOnMinRdsOn):
2.5V, 10V
RdsOn(Max)@IdVgs:
75mOhm @ 2.2A, 10V
Vgs(th)(Max)@Id:
1.4V @ 250µA
GateCharge(Qg)(Max)@Vgs:
15.6 nC @ 10 V
Vgs(Max):
±12V
InputCapacitance(Ciss)(Max)@Vds:
720 pF @ 15 V
FETFeature:
-
PowerDissipation(Max):
480mW (Ta)
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
