ON Semiconductor NTB004N10G

Part No.:: NTB004N10G

Manufacturer:: ON Semiconductor

Package:: D²PAK-3 (TO-263-3)

Datasheet:: NTB004N10G.pdf

Description:: MOSFET N-CH 100V 201A TO263

In Stock:: 3332

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

NTB004N10G Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
100 V
Current-ContinuousDrain(Id)@25°C:
201A (Ta)
DriveVoltage(MaxRdsOnMinRdsOn):
10V
RdsOn(Max)@IdVgs:
4.2mOhm @ 100A, 10V
Vgs(th)(Max)@Id:
4V @ 500µA
GateCharge(Qg)(Max)@Vgs:
175 nC @ 10 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
11900 pF @ 50 V
FETFeature:
-
PowerDissipation(Max):
340W (Tc)
OperatingTemperature:
-55°C ~ 175°C (TJ)
MountingType:
Surface Mount

NTB004N10G this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including NTB004N10G price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for NTB004N10G to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

NTB004N10G information

Views：

NTB004N10G Typical application Circuitry

NTB004N10G

The NTB004N10G is a high-performance N-channel MOSFET designed for use in power conversion and management applications. It's characterized by its high drain-to-source voltage (V_DS), low on-resistance (R_DS(on)), and high current carrying capability, making it an excellent choice for efficient power switching in a variety of applications, including DC-DC converters, motor drives, and power supply units.

Application Scenario: DC-DC Converter

One common application of the NTB004N10G is in DC-DC converters, which are used to convert one DC voltage level to another. These converters are essential in gadgets like laptops, cellphones, and many kinds of industrial machinery that have varying voltage requirements for various components.

Detailed Circuit Connection

1.Switching Element: In a DC-DC converter circuit, the NTB004N10G serves as the primary switching element. Connect the drain (D) of the NTB004N10G to the positive side of the input voltage supply. This configuration allows the MOSFET to control the flow of energy from the input supply to the rest of the circuit.

2.Gate Drive: In order to manage the MOSFET's on and off times, the gate (G) of the NTB004N10G needs a gate drive circuit. A PWM (Pulse Width Modulation) signal is typically applied to the gate to regulate the output voltage of the DC-DC converter. This gate drive circuit must be capable of supplying sufficient voltage and current to switch the NTB004N10G efficiently and quickly, minimizing transition losses.

3.Source Connection: The NTB004N10G's source (S) is wired to the circuit's ground. This establishes a reference point for the gate drive circuit and completes the path for current flow through the MOSFET when it is turned on.

4.Flyback Diode: A flyback diode is placed across the load (or the inductor in a buck converter configuration) to protect the NTB004N10G from voltage spikes caused by the inductive load when the MOSFET is turned off. The NTB004N10G's cathode is connected to its drain, while its anode is connected to its source, or ground in this case.

5.Output Filtering: The output of the DC-DC converter typically includes a filter, consisting of an inductor and a capacitor, to smooth out the PWM switching noise and provide a stable DC output. For the converter to operate well and behave as intended, these parts must be placed.

Design Considerations

When designing a circuit with the NTB004N10G, several factors must be considered:

- Gate Drive Requirements: Ensure the gate drive circuit can provide adequate voltage and current to the NTB004N10G gate. Insufficient gate drive can result in higher R_DS(on) and increased switching losses.

- Thermal Management: The NTB004N10G can dissipate significant heat during operation. Proper thermal management, including heat sinks and thermal vias, is essential to maintain performance and prevent overheating.

- Parasitic Inductances: Minimize parasitic inductances in the circuit layout, especially in the gate drive path and the source return path. These inductances have the potential to increase switching losses and slow down switching speed.

- Features of Protection: To protect the NTB004N10G and the circuit from unusual operating situations, include protective features including over-current and over-temperature protection.

- Efficiency Optimization: Optimize the circuit components and layout to maximize efficiency. This includes selecting appropriate values for the output filter components and minimizing resistance in the current path.

To sum up, the NTB004N10G is an effective part for applications requiring high power conversion efficiency. By carefully considering the detailed circuit connections and design considerations, engineers can effectively utilize the NTB004N10G to build reliable and efficient power management systems.
