ON Semiconductor NDT3055L

Part No.:: NDT3055L

Manufacturer:: ON Semiconductor

Package:: SOT-223-4

Datasheet:: NDT3055L.pdf

Description:: MOSFET N-CH 60V 4A SOT-223-4

In Stock:: 3406

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

NDT3055L Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
-
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
60 V
Current-ContinuousDrain(Id)@25°C:
4A (Ta)
DriveVoltage(MaxRdsOnMinRdsOn):
4.5V, 10V
RdsOn(Max)@IdVgs:
100mOhm @ 4A, 10V
Vgs(th)(Max)@Id:
2V @ 250µA
GateCharge(Qg)(Max)@Vgs:
20 nC @ 10 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
345 pF @ 25 V
FETFeature:
-
PowerDissipation(Max):
3W (Ta)
OperatingTemperature:
-65°C ~ 150°C (TJ)
MountingType:
Surface Mount

NDT3055L this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including NDT3055L price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for NDT3055L to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

NDT3055L information

Views：

NDT3055L Typical application Circuitry

NDT3055L

For high-speed switching applications, the NDT3055L is an N-Channel Enhancement Mode Field Effect Transistor (MOSFET).

Utilization:

This MOSFET finds its use in various applications like DC-DC converters, motor drivers, power management in consumer electronics, and switching regulators.

Parameter Features:

- Drain-Source Voltage (Vdss): Indicates the maximum voltage that the MOSFET can withstand from drain to source.

- Continuous Drain Current (Id): The highest continuous current that can pass via the drain.

- Gate Threshold Voltage (Vgs(th)): The voltage at which the MOSFET conducts.

- Rds(On): On-state resistance between drain and source, a lower value means less power dissipation.

Example Circuit – Motor Driver:

1. Motor Connection: Connect the motor's positive terminal to the Drain (pin 3) of NDT3055L.

2. Power Supply: Connect the motor's negative terminal to the power supply's negative terminal.

3. Source to Ground: Tie the Source (pin 2) of the NDT3055L to the ground.

4. Gate Voltage Control: Interface a microcontroller's PWM output through a current-limiting resistor to the Gate (pin 1) for controlling motor speed. Ensure the gate voltage is sufficient to fully turn on the MOSFET.

Design Considerations:

1. Gate Drive: Ensure the microcontroller can provide adequate voltage to fully turn on the NDT3055L.

2. Heat Dissipation: Depending on the motor's power, a heatsink might be necessary to keep the MOSFET from overheating.

3. Protection Circuits: Implement flyback diodes across the motor to protect the MOSFET from inductive voltage spikes.

4. Switching Frequency: Higher frequencies require careful layout to minimize parasitic inductances.

Employing the NDT3055L in a motor driver circuit exemplifies its aptitude for rapid switching applications. For precise specifications and characteristics, consulting the datasheet is imperative when designing your circuit.
