ON Semiconductor NDS7002A-F169

Part No.:: NDS7002A-F169

Manufacturer:: ON Semiconductor

Package:: SOT-23-3

Datasheet:

Description:: MOSFET N-CH SOT23

In Stock:: 3131

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

NDS7002A-F169 Specifications

Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Obsolete
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
60 V
Current-ContinuousDrain(Id)@25°C:
280mA (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
5V, 10V
RdsOn(Max)@IdVgs:
2Ohm @ 500mA, 10V
Vgs(th)(Max)@Id:
2.5V @ 250µA
GateCharge(Qg)(Max)@Vgs:
-
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
50 pF @ 25 V
FETFeature:
-
PowerDissipation(Max):
300mW (Tc)
OperatingTemperature:
-65°C ~ 150°C (TJ)
MountingType:
Surface Mount
