ON Semiconductor NDS355AN-F169

Part No.:: NDS355AN-F169

Manufacturer:: ON Semiconductor

Package:: SOT-23-3

Datasheet:: NDS355AN-F169.pdf

Description:: MOSFET N-CH 30V 1.7A SOT23-3

In Stock:: 3240

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

NDS355AN-F169 Specifications

Packaging:
Tray
Series:
-
ProductStatus:
Obsolete
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
30 V
Current-ContinuousDrain(Id)@25°C:
1.7A (Ta)
DriveVoltage(MaxRdsOnMinRdsOn):
4.5V, 10V
RdsOn(Max)@IdVgs:
85mOhm @ 1.9A, 10V
Vgs(th)(Max)@Id:
2V @ 250µA
GateCharge(Qg)(Max)@Vgs:
5 nC @ 5 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
195 pF @ 15 V
FETFeature:
-
PowerDissipation(Max):
500mW (Ta)
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
