Infineon Technologies IRFP4110PBF

Part No.:: IRFP4110PBF

Manufacturer:: Infineon Technologies

Package:: TO-247AC

Datasheet:: IRFP4110PBF.pdf

Description:: MOSFET N-CH 100V 120A TO247AC

In Stock:: 2748

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

IRFP4110PBF Specifications

Packaging:
Tube
Series:
HEXFET®
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
100 V
Current-ContinuousDrain(Id)@25°C:
120A (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
10V
RdsOn(Max)@IdVgs:
4.5mOhm @ 75A, 10V
Vgs(th)(Max)@Id:
4V @ 250µA
GateCharge(Qg)(Max)@Vgs:
210 nC @ 10 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
9620 pF @ 50 V
FETFeature:
-
PowerDissipation(Max):
370W (Tc)
OperatingTemperature:
-55°C ~ 175°C (TJ)
MountingType:
Through Hole

IRFP4110PBF this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including IRFP4110PBF price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for IRFP4110PBF to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

IRFP4110PBF information

Views：

IRFP4110PBF Typical application Circuitry

IRFP4110PBF

The IRFP4110PBF, hailing from International Rectifier's esteemed HEXFET series, exemplifies the evolution of power MOSFETs with an emphasis on energy efficiency, low on-resistance, and high current capabilities. This N-channel MOSFET offers the promise of streamlined power conversion, making it a prime choice for diverse applications from switched-mode power supplies to motor controls. Within the vast panorama of power electronics, the IRFP4110PBF commands attention due to its superior attributes. Let's delve into its intricate details, accentuating on accurate circuit integration down to the pin-level.

1. Drain (D): Being the channel's termination point, the Drain pin is typically connected to the positive side of the load. Depending on the application's design, it can either connect directly to the power supply or, in switch configurations, connect through the load itself.

2. Gate (G):

- As the MOSFET's command center, the Gate pin receives the control signal that dictates the switch's ON or OFF status. To drive the IRFP4110PBF effectively, this pin should be connected to the output of a MOSFET driver or a microcontroller, ensuring the applied voltage is within the specified gate-source threshold.

- For optimal protection and performance, consider integrating a gate resistor in series with the Gate pin. This resistor acts as a cushion, mitigating voltage spikes and potential oscillations.

3. Source (S): The Source pin is often linked to the circuit's ground or common reference. In some configurations, particularly where the IRFP4110PBF operates in a high-side switch design, the Source may connect to other circuit nodes.

4. Constructive Insights for Circuitry Integration:

- Gate Protection: Integrate a zener diode between the Gate and Source pins of the IRFP4110PBF. This protective measure clamps the gate voltage, shielding the MOSFET from potential over-voltage scenarios.

- Flyback Diode: When deploying the IRFP4110PBF in inductive load applications, ensure the inclusion of a flyback diode. This diode is critical in preventing harmful voltage spikes during switching transitions.

- Thermal Management: Given that power MOSFETs can become considerably warm during operation, especially when dealing with high currents, incorporating efficient heat sinks with the IRFP4110PBF is paramount. Ensure the MOSFET's mounting surface has a good thermal connection to dissipate heat efficiently.

- Safety Protocols: It's imperative to confirm the operating conditions of the IRFP4110PBF. This encompasses validating that the applied voltages and currents don't surpass the component's ratings.
