Infineon Technologies IRF8736TRPBF

Part No.:: IRF8736TRPBF

Manufacturer:: Infineon Technologies

Package:: 8-SO

Datasheet:: IRF8736TRPBF.pdf

Description:: MOSFET N-CH 30V 18A 8SO

In Stock:: 50921

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

IRF8736TRPBF Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
HEXFET®
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
30 V
Current-ContinuousDrain(Id)@25°C:
18A (Ta)
DriveVoltage(MaxRdsOnMinRdsOn):
4.5V, 10V
RdsOn(Max)@IdVgs:
4.8mOhm @ 18A, 10V
Vgs(th)(Max)@Id:
2.35V @ 50µA
GateCharge(Qg)(Max)@Vgs:
26 nC @ 4.5 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
2315 pF @ 15 V
FETFeature:
-
PowerDissipation(Max):
2.5W (Ta)
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
