Infineon Technologies IPT60R022S7XTMA1

Part No.:: IPT60R022S7XTMA1

Manufacturer:: Infineon Technologies

Package:: PG-HSOF-8-2

Datasheet:

Description:: MOSFET N-CH 600V 23A 8HSOF

In Stock:: 2658

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

IPT60R022S7XTMA1 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
CoolMOS™S7
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
600 V
Current-ContinuousDrain(Id)@25°C:
23A (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
12V
RdsOn(Max)@IdVgs:
22mOhm @ 23A, 12V
Vgs(th)(Max)@Id:
4.5V @ 1.44mA
GateCharge(Qg)(Max)@Vgs:
150 nC @ 12 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
5639 pF @ 300 V
FETFeature:
-
PowerDissipation(Max):
390W (Tc)
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
