Infineon Technologies IPB014N06NATMA1

Part No.:: IPB014N06NATMA1

Manufacturer:: Infineon Technologies

Package:: PG-TO263-7

Datasheet:: IPB014N06NATMA1.pdf

Description:: MOSFET N-CH 60V 34A/180A TO263-7

In Stock:: 2681

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

IPB014N06NATMA1 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
OptiMOS™
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
60 V
Current-ContinuousDrain(Id)@25°C:
34A (Ta), 180A (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
6V, 10V
RdsOn(Max)@IdVgs:
1.4mOhm @ 100A, 10V
Vgs(th)(Max)@Id:
2.8V @ 143µA
GateCharge(Qg)(Max)@Vgs:
106 nC @ 10 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
7800 pF @ 30 V
FETFeature:
-
PowerDissipation(Max):
3W (Ta), 214W (Tc)
OperatingTemperature:
-55°C ~ 175°C (TJ)
MountingType:
Surface Mount

IPB014N06NATMA1 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including IPB014N06NATMA1 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for IPB014N06NATMA1 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

IPB014N06NATMA1 information

Views：

IPB014N06NATMA1 Typical application Circuitry

IPB014N06NATMA1

IPB014N06NATMA1 is a high-performance N-channel power MOSFET designed for exceptional efficiency and power handling in various applications. Its advanced technology ensures reduced conduction and switching losses, making it suitable for high-frequency power conversion systems.

Application Scenarios

IPB014N06NATMA1 is commonly used in applications such as DC-DC converters, motor drives, power management systems, and other high-performance power conversion and switching applications.

Parameter Features

- High Current Capability: This MOSFET can handle high levels of current, making it suitable for applications requiring high power density.

- Low On-Resistance: The gadget has an extremely low on-resistance, which raises efficiency and reduces power losses.

- Fast Switching Speed: It is designed for fast switching, reducing energy losses during the transition periods of switching operations.

Circuit Connection in a Specific Application Scenario

Let's consider a DC-DC converter as an application for the IPB014N06NATMA1. Here's a detailed method for connecting the circuit:

- Power Source Connection: Connect the input power source to the converter circuit. Verify that the power supply meets the IPB014N06NATMA1's voltage and current requirements.

- Inductor and Capacitor for Energy Storage: Connect an inductor to the drain of the IPB014N06NATMA1 to store energy during the on phase and release it during the off phase. A capacitor should be connected at the output to filter the output and provide a stable DC voltage.

- PWM Controller for Gate Control: Use a PWM controller to generate the control signal for the IPB014N06NATMA1. The controller's output should be connected to the gate of the MOSFET, controlling its on and off states to regulate the output voltage.

- Gate Resistor for Damping: Insert a resistor between the PWM controller and the gate of the IPB014N06NATMA1 to limit the gate current and provide damping to reduce ringing and overshoot in the gate drive signal.

- Feedback Loop for Output Regulation: Implement a feedback loop from the output to the PWM controller to adjust the duty cycle based on the output voltage. This guarantees that the output voltage won't fluctuate based on changes in the input voltage or the load.

- Protection Circuits for Safety: Design the circuit with protective features such as overcurrent protection, thermal shutdown, and under-voltage lockout to protect the IPB014N06NATMA1 and the overall circuit from adverse conditions.

- Thermal Management for Heat Dissipation: Employ appropriate cooling techniques, such as heat sinks or thermal pads, to manage the heat generated by the IPB014N06NATMA1 and maintain its performance within the specified temperature range.

It is essential to take the application's electrical and thermal requirements into account while developing with the IPB014N06NATMA1. The layout of the PCB should be optimized to minimize parasitic inductances and resistances, ensuring efficient operation of the MOSFET. Additionally, proper selection of external components such as the inductor, capacitor, and resistors is essential to achieve the desired performance and reliability of the DC-DC converter.
