Name: FQPF27P06
Brand: ON Semiconductor
SKU: FQPF27P06
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

ON Semiconductor FQPF27P06

Part No.:: FQPF27P06

Manufacturer:: ON Semiconductor

Package:: TO-220F-3

Datasheet:: FQPF27P06.pdf

Description:: MOSFET P-CH 60V 17A TO220F

In Stock:: 2579

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

FQPF27P06 Specifications

Packaging:
Bulk,Tube
Series:
QFET®
ProductStatus:
Active
FETType:
P-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
60 V
Current-ContinuousDrain(Id)@25°C:
17A (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
10V
RdsOn(Max)@IdVgs:
70mOhm @ 8.5A, 10V
Vgs(th)(Max)@Id:
4V @ 250µA
GateCharge(Qg)(Max)@Vgs:
43 nC @ 10 V
Vgs(Max):
±25V
InputCapacitance(Ciss)(Max)@Vds:
1400 pF @ 25 V
FETFeature:
-
PowerDissipation(Max):
47W (Tc)
OperatingTemperature:
-55°C ~ 175°C (TJ)
MountingType:
Through Hole

FQPF27P06 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including FQPF27P06 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for FQPF27P06 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

FQPF27P06 information

Views：

FQPF27P06 Typical application Circuitry

FQPF27P06

In today's sophisticated electronic landscape, the FQPF27P06 carves its niche. It isn't just any component, but a P-Channel MOSFET, and this distinction carries immense significance. Its inherent properties make it an indispensable ally for various applications.

Now, the question arises: why exactly is the FQPF27P06 so revered? Firstly, it's a P-Channel MOSFET designed for high voltage operations. This characteristic allows it to switch high-voltage loads efficiently and quickly.

Several applications resonate with its abilities. From power management in computers to switching operations in motor control circuits, and even high-frequency inverters, the FQPF27P06 is a recurring choice.

Key Features:

1. Voltage Ratings: This P-Channel MOSFET is designed to handle significant negative voltage, typically -60V.

2. Current Handling: The FQPF27P06 can cater to a continuous drain current of about -27A, making it suitable for hefty applications.

3. Low On-Resistance: Its on-resistance is commendably low, which means the voltage drop and power loss when the MOSFET is on are minimized.

4. Fast Switching: This feature enables it to be used in applications where rapid transitions between on and off states are crucial.

Illustrative Application: Motor Control Circuit:

Let's delve into a practical scenario where the FQPF27P06 serves as a motor controller for a DC motor:

1. Source Pin: As a common practice, connect the source of the FQPF27P06 directly to the positive terminal of the power supply.

2. Gate Pin: This is where you'll control the MOSFET. The FQPF27P06 activates when a negative voltage is provided to the gate (relative to the source). Use a microcontroller or a PWM (Pulse Width Modulation) generator to provide this control voltage.

3. Drain Pin: Connect the drain of the MOSFET to one terminal of the DC motor. The other end of the motor should be connected to the power supply's ground or negative terminal.

4. Protection: Consider integrating a flyback diode in parallel with the motor. This diode protects the FQPF27P06 from voltage spikes caused by the motor's inductive nature.

Design Considerations:

1. Gate Drive: Ensure the gate drive circuitry can provide sufficient voltage to turn the FQPF27P06 fully on.

2. Thermal Management: Like any power component, the FQPF27P06 can get hot. Provision for heat dissipation, perhaps through heatsinks, is prudent.

3. Protection Mechanisms: Beyond the flyback diode, consider other protective elements like fuses or current sensors to safeguard against potential mishaps.

4. Switching Frequencies: Remember, the FQPF27P06 can handle fast switching. If your application involves high-frequency operations, ensure the rest of the circuit components are compatible.

In summation, the FQPF27P06 is a testament to the advances in semiconductor technology, a P-Channel MOSFET that doesn't merely function but excels, making it a favorite amongst circuit designers globally.
