ON Semiconductor FDPF33N25TRDTU

Part No.:: FDPF33N25TRDTU

Manufacturer:: ON Semiconductor

Package:: TO-220F (LG-Formed)

Datasheet:: FDPF33N25TRDTU.pdf

Description:: MOSFET N-CHANNEL 250V TO220F

In Stock:: 432

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

FDPF33N25TRDTU Specifications

Packaging:
Tube
Series:
-
ProductStatus:
Obsolete
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
250 V
Current-ContinuousDrain(Id)@25°C:
33A (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
10V
RdsOn(Max)@IdVgs:
94mOhm @ 16.5A, 10V
Vgs(th)(Max)@Id:
5V @ 250µA
GateCharge(Qg)(Max)@Vgs:
48 nC @ 10 V
Vgs(Max):
±30V
InputCapacitance(Ciss)(Max)@Vds:
2135 pF @ 25 V
FETFeature:
-
PowerDissipation(Max):
37W (Tc)
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Through Hole
