ON Semiconductor FDPF33N25T

Part No.:: FDPF33N25T

Manufacturer:: ON Semiconductor

Package:: TO-220F-3

Datasheet:: FDPF33N25T.pdf

Description:: MOSFET N-CH 250V 33A TO220F

In Stock:: 8179

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

FDPF33N25T Specifications

Packaging:
Tube
Series:
UniFET™
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
250 V
Current-ContinuousDrain(Id)@25°C:
33A (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
10V
RdsOn(Max)@IdVgs:
94mOhm @ 16.5A, 10V
Vgs(th)(Max)@Id:
5V @ 250µA
GateCharge(Qg)(Max)@Vgs:
48 nC @ 10 V
Vgs(Max):
±30V
InputCapacitance(Ciss)(Max)@Vds:
2135 pF @ 25 V
FETFeature:
-
PowerDissipation(Max):
37W (Tc)
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Through Hole

FDPF33N25T this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including FDPF33N25T price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for FDPF33N25T to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

FDPF33N25T information

Views：

FDPF33N25T Typical application Circuitry

FDPF33N25T

The FDPF33N25T is a N-channel MOSFET transistor designed by ON Semiconductor.Power management applications including switching regulators, power inverters, and motor drivers choose it because of its high voltage and current handling capabilities.

Features of FDPF33N25T:

1. Drain-Source Voltage (Vdss): 250V This is the highest voltage that the MOSFET is capable of supporting between its source and drain terminals.

2. Continuous Drain Current (Id): 33A, highlighting the maximum current the device can conduct continuously.

3. On-Resistance (Rdson): 0.085Ω at Vgs = 10V, showcasing the resistance between the drain and source when the MOSFET is in the on state.

4. Gate-Source Voltage (Vgs): The maximum voltage that can be placed between the gate and source terminals is indicated by the notation ±30V.

Utilization in an Intermittent Power Source:

Because of its effectiveness in handling high voltage and current, the FDPF33N25T is frequently utilized in switching power supply circuits.

An Introduction to Circuit Connections

1. Power source connector: Join the drain terminal (D) of the FDPF33N25T with the positive connector from the power source.

2. Load Connection: Attach the load to the source terminal (S) of the FDPF33N25T, with the other end of the load connected to the ground.

3. Gate Drive: Connect the gate terminal (G) to the output of a PWM controller, which will drive the gate voltage to turn the MOSFET on and off.

4. Flyback Diode: To safeguard the MOSFET against voltage spikes resulting from inductive loads, place a flyback diode across the load.

Design Points to Remember:

- Gate Drive Voltage: Verify that the gate drive voltage is both within the designated Vgs range and high enough to completely activate the MOSFET.

- Heat Dissipation: Use appropriate cooling or heat-sink techniques to control the heat produced by the MOSFET while it is operating.

- Parasitic Inductance: To lessen voltage overshoot and switching losses, minimize parasitic inductance in the circuit design.

- Protection Features: Consider integrating overcurrent and overtemperature protection features to enhance system reliability.

In switching power supply circuits, the FDPF33N25T serves as a critical component in the switching mechanism, enabling efficient conversion of input voltage to a regulated output voltage. Designing a circuit with this MOSFET requires careful consideration of gate drive requirements, thermal management, layout optimization, and protective measures to ensure efficient and reliable operation.
