ON Semiconductor FDMS86163P

Part No.:: FDMS86163P

Manufacturer:: ON Semiconductor

Package:: 8-PQFN (5x6)

Datasheet:: FDMS86163P.pdf

Description:: MOSFET P-CH 100V 7.9A/50A 8PQFN

In Stock:: 811

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

FDMS86163P Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
PowerTrench®
ProductStatus:
Active
FETType:
P-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
100 V
Current-ContinuousDrain(Id)@25°C:
7.9A (Ta), 50A (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
6V, 10V
RdsOn(Max)@IdVgs:
22mOhm @ 7.9A, 10V
Vgs(th)(Max)@Id:
4V @ 250µA
GateCharge(Qg)(Max)@Vgs:
59 nC @ 10 V
Vgs(Max):
±25V
InputCapacitance(Ciss)(Max)@Vds:
4085 pF @ 50 V
FETFeature:
-
PowerDissipation(Max):
2.5W (Ta), 104W (Tc)
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
