ON Semiconductor FDMS86150ET100

Part No.:: FDMS86150ET100

Manufacturer:: ON Semiconductor

Package:: 8-PQFN (5x6)

Datasheet:: FDMS86150ET100.pdf

Description:: MOSFET N-CH 100V 16A POWER56

In Stock:: 3000

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

FDMS86150ET100 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
PowerTrench®
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
100 V
Current-ContinuousDrain(Id)@25°C:
16A (Ta), 128A (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
6V, 10V
RdsOn(Max)@IdVgs:
4.85mOhm @ 16A, 10V
Vgs(th)(Max)@Id:
4V @ 250µA
GateCharge(Qg)(Max)@Vgs:
62 nC @ 10 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
4065 pF @ 50 V
FETFeature:
-
PowerDissipation(Max):
3.3W (Ta), 187W (Tc)
OperatingTemperature:
-55°C ~ 175°C (TJ)
MountingType:
Surface Mount

FDMS86150ET100 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including FDMS86150ET100 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for FDMS86150ET100 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

FDMS86150ET100 information

Views：

FDMS86150ET100 Typical application Circuitry

FDMS86150ET100

The FDMS86150ET100 is a specific model within the family of PowerTrench® MOSFETs, designed for high efficiency and reliability in power conversion and management applications.

Application Scenario: High-Frequency DC-DC Converters

In high-frequency DC-DC converters, the FDMS86150ET100 could be used to efficiently switch the input voltage to a regulated output voltage with minimal losses, which is crucial in applications requiring precise voltage regulation such as in telecommunications and server power supplies.

Key Parameters:

- Low On-Resistance (RDS(on)): Essential for reducing conduction losses, thereby enhancing the overall efficiency of the DC-DC converter.

- High Current Capability: Enables the MOSFET to handle the substantial current flows typical in power conversion applications without overheating or performance degradation.

- Fast Switching Speed: Reduces switching losses, which is particularly important in high-frequency converters where the MOSFET needs to turn on and off rapidly.

- Robust Thermal Performance: Ensures the MOSFET can operate reliably under various thermal conditions, a critical aspect for maintaining performance and longevity in compact, high-power applications.

Specific Circuit Connection in High-Frequency DC-DC Converters:

Primary Switching Component

- Pin Configuration: Connect the drain of the FDMS86150ET100 to the input power supply. The source pin should be connected to the common ground, and the gate pin is interfaced with the PWM (Pulse Width Modulation) control circuit, which dictates the switching behavior of the MOSFET.

- Gate Drive Circuit: A specialized gate drive circuit is necessary to precisely control the gate voltage of the FDMS86150ET100, ensuring efficient and swift switching. This circuit must be capable of providing sufficient drive current to quickly charge and discharge the gate capacitance.

- Protection Mechanisms: Implementing protection schemes such as overcurrent, overvoltage, and thermal protection in the circuit is crucial to prevent damage to the FDMS86150ET100 under fault conditions, thereby enhancing the safety and reliability of the DC-DC converter.

Design Considerations:

- Thermal Management: Effective thermal management strategies, including the use of heat sinks or cooling fans, are essential to keep the FDMS86150ET100 within its safe operating temperature range, especially in high-power or high-frequency applications.

- Gate Drive Strength: The gate drive circuit needs to ensure that it can deliver the necessary voltage and current to the gate of the FDMS86150ET100 for rapid and reliable switching, which directly impacts the converter's efficiency and performance.

- Layout and Parasitics: Careful PCB layout to minimize loop areas and parasitic inductances is crucial to reduce switching losses and electromagnetic interference (EMI) generated by the FDMS86150ET100, improving the performance and reliability of the DC-DC converter.

- Protection and Safety: Integrating comprehensive protection features to address potential overcurrent, overvoltage, and overheating scenarios is vital for ensuring that the FDMS86150ET100 operates within safe parameters, contributing to the overall safety and reliability of the high-frequency DC-DC converter.

Incorporating these considerations in the design phase allows the FDMS86150ET100 to effectively contribute to the efficiency, compactness, and reliability of high-frequency DC-DC converters, meeting the stringent requirements of modern electronic systems.
