ON Semiconductor FDD4141-F085P

Part No.:: FDD4141-F085P

Manufacturer:: ON Semiconductor

Package:: TO-252AA

Datasheet:: FDD4141-F085P.pdf

Description:: MOSFET P-CH 40V 10.8A/50A TO252

In Stock:: 2829

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

FDD4141-F085P Specifications

Packaging:
Tape & Reel (TR)
Series:
Automotive, AEC-Q101, PowerTrench®
ProductStatus:
Obsolete
FETType:
P-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
40 V
Current-ContinuousDrain(Id)@25°C:
10.8A (Ta), 50A (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
4.5V, 10V
RdsOn(Max)@IdVgs:
12.3mOhm @ 12.7A, 10V
Vgs(th)(Max)@Id:
3V @ 250µA
GateCharge(Qg)(Max)@Vgs:
50 nC @ 10 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
2775 pF @ 20 V
FETFeature:
-
PowerDissipation(Max):
2.4W (Ta), 69W (Tc)
OperatingTemperature:
-55°C ~ 175°C (TJ)
MountingType:
Surface Mount
