ON Semiconductor FDC2612

Part No.:: FDC2612

Manufacturer:: ON Semiconductor

Package:: SuperSOT™-6

Datasheet:: FDC2612.pdf

Description:: MOSFET N-CH 200V 1.1A SUPERSOT6

In Stock:: 3124

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

FDC2612 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
PowerTrench®
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
200 V
Current-ContinuousDrain(Id)@25°C:
1.1A (Ta)
DriveVoltage(MaxRdsOnMinRdsOn):
10V
RdsOn(Max)@IdVgs:
725mOhm @ 1.1A, 10V
Vgs(th)(Max)@Id:
4.5V @ 250µA
GateCharge(Qg)(Max)@Vgs:
11 nC @ 10 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
234 pF @ 100 V
FETFeature:
-
PowerDissipation(Max):
1.6W (Ta)
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
