ON Semiconductor FDC2512-P

Part No.:: FDC2512-P

Manufacturer:: ON Semiconductor

Package:: SuperSOT™-6

Datasheet:

Description:: MOSFET N-CH 150V SUPERSOT6

In Stock:: 2458

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

FDC2512-P Specifications

Packaging:
Tape & Reel (TR)
Series:
PowerTrench®
ProductStatus:
Obsolete
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
150 V
Current-ContinuousDrain(Id)@25°C:
1.4A (Ta)
DriveVoltage(MaxRdsOnMinRdsOn):
6V, 10V
RdsOn(Max)@IdVgs:
425mOhm @ 1.4A, 10V
Vgs(th)(Max)@Id:
4V @ 250µA
GateCharge(Qg)(Max)@Vgs:
11 nC @ 10 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
344 pF @ 75 V
FETFeature:
-
PowerDissipation(Max):
800mW (Ta)
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount

FDC2512-P this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including FDC2512-P price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for FDC2512-P to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

FDC2512-P information

Views：

FDC2512-P Typical application Circuitry

FDC2512-P

The FDC2512-P is a N-Channel MOSFET, which is a type of transistor used for switching and amplifying electrical signals. This specific model is tailored for applications requiring efficient handling of moderate power levels.

Applications of the FDC2512-P

- Power Supply Circuits: This MOSFET is suitable for switching in power supply units, managing the flow and conversion of electrical energy.

- Motor Control Systems: It can be used in the control circuits of electric motors, providing efficient switching and control of motor operation.

- Audio Amplifiers: The FDC2512-P can be a component in audio systems where signal amplification is needed.

Parameter Features of the FDC2512-P

- It has a continuous drain current of 1.4 A, indicating its capability to handle this level of current continuously.

- The drain to source breakdown voltage is 150 V, which is the maximum voltage it can block when off.

- It features a drain to source resistance of 425 mΩ, a measure of its efficiency in the conducting state.

- The maximum power dissipation is 1.6 W, defining the limit of power it can handle before needing heat dissipation measures.

Circuit Implementation Example: Power Supply Circuit

1. Power Source Connection: The FDC2512-P's source pin needs to be linked to the DC power supply's negative terminal.

2. Load Integration: Attach the drain pin to the load, ensuring the other end of the load connects back to the positive terminal of the power source.

3. Control Via Gate: The gate pin needs connection to a control circuit, such as a microcontroller, to manage the switching operation of the MOSFET.

4. Heat Management: Considering its power dissipation capacity, attaching a heat sink to the FDC2512-P is advisable, especially in applications where it operates near its maximum power dissipation limit.

Design Considerations with the FDC2512-P

- Thermal Management: Proper cooling is crucial, given the power dissipation characteristics.

- Gate Drive Considerations: The voltage and current supplied to the gate must be within specified limits to ensure reliable operation.

- Protection Features: Implementing overcurrent and overvoltage protection can safeguard the MOSFET from potential damage.

- Circuit Layout: The layout should minimize resistance and inductance to optimize the MOSFET's performance.

In conclusion, the FDC2512-P is a versatile N-Channel MOSFET that can be effectively utilized in various electronic circuits where efficient switching and moderate power handling are required.For best results and dependability in their applications, designers should consider its electrical properties and thermal management.
