Fairchild Semiconductor FCI25N60N-F102

Part No.:: FCI25N60N-F102

Manufacturer:: Fairchild Semiconductor

Package:: I2PAK (TO-262)

Datasheet:: FCI25N60N-F102.pdf

Description:: MOSFET N-CH 600V 25A I2PAK

In Stock:: 787

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

FCI25N60N-F102 Specifications

Packaging:
Bulk
Series:
SupreMOS™
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
600 V
Current-ContinuousDrain(Id)@25°C:
25A (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
10V
RdsOn(Max)@IdVgs:
125mOhm @ 12.5A, 10V
Vgs(th)(Max)@Id:
4V @ 250µA
GateCharge(Qg)(Max)@Vgs:
74 nC @ 10 V
Vgs(Max):
±30V
InputCapacitance(Ciss)(Max)@Vds:
3352 pF @ 100 V
FETFeature:
-
PowerDissipation(Max):
216W (Tc)
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Through Hole
