ON Semiconductor FCH040N65S3-F155

Part No.:: FCH040N65S3-F155

Manufacturer:: ON Semiconductor

Package:: TO-247-3

Datasheet:: FCH040N65S3-F155.pdf

Description:: MOSFET N-CH 650V 65A TO247-3

In Stock:: 2225

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

FCH040N65S3-F155 Specifications

Packaging:
Bulk,Tube
Series:
SuperFET® III
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
650 V
Current-ContinuousDrain(Id)@25°C:
65A (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
10V
RdsOn(Max)@IdVgs:
40mOhm @ 32.5A, 10V
Vgs(th)(Max)@Id:
4.5V @ 6.5mA
GateCharge(Qg)(Max)@Vgs:
136 nC @ 10 V
Vgs(Max):
±30V
InputCapacitance(Ciss)(Max)@Vds:
4740 pF @ 400 V
FETFeature:
-
PowerDissipation(Max):
417W (Tc)
OperatingTemperature:
-55°C ~ 150°C
MountingType:
Through Hole
