Texas Instruments CSD18534Q5A

Part No.:: CSD18534Q5A

Manufacturer:: Texas Instruments

Package:: 8-VSONP (5x6)

Datasheet:: CSD18534Q5A.pdf

Description:: MOSFET N-CH 60V 13A/50A 8VSON

In Stock:: 3874

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

CSD18534Q5A Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
NexFET™
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
60 V
Current-ContinuousDrain(Id)@25°C:
13A (Ta), 50A (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
4.5V, 10V
RdsOn(Max)@IdVgs:
9.8mOhm @ 14A, 10V
Vgs(th)(Max)@Id:
2.3V @ 250µA
GateCharge(Qg)(Max)@Vgs:
22 nC @ 10 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
1770 pF @ 30 V
FETFeature:
-
PowerDissipation(Max):
3.1W (Ta), 77W (Tc)
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount

CSD18534Q5A this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including CSD18534Q5A price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for CSD18534Q5A to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

CSD18534Q5A information

Views：

CSD18534Q5A Typical application Circuitry

CSD18534Q5A

The CSD18534Q5A is an integral member of Texas Instruments' NexFET™ technology portfolio, specifically designed for high-efficiency power conversion applications. This device, a single N-Channel MOSFET, is optimized for applications requiring low on-resistance and high power efficiency, such as power supply circuits, motor controls, and various types of converters. The CSD18534Q5A is engineered to meet the demands of high-performance power management with its exceptional thermal and electrical characteristics.

1. Hallmarks of the CSD18534Q5A Series: Characterized by its low on-resistance and high power efficiency, the CSD18534Q5A excels in minimizing conduction losses, a critical factor in power-intensive applications. The device's fast switching capability enhances its performance in high-frequency circuits by reducing transition losses. Additionally, the CSD18534Q5A is designed to offer superior thermal management, ensuring device reliability and longevity even under strenuous conditions.

2. Pin Configuration and Connectivity Blueprint: Housed in a compact SON 5x6 package, the CSD18534Q5A features a straightforward pin layout conducive to seamless circuit integration. The device includes a drain (D) terminal at pin 1, which also connects to the thermal pad to facilitate efficient heat dissipation. The gate (G) terminal, located at pin 2, serves as the control input. The source (S) terminals, spread across pins 3, 4, 5, and 6, ensure a low-resistance path for current flow, crucial for the device's efficient operation.

3. Circuit Integration Approach for the CSD18534Q5A: Incorporating the CSD18534Q5A into a circuit demands careful attention to the gate drive mechanism to guarantee precise and swift switching. It is essential to establish robust connections from the source pins to the ground plane and from the drain pin to the load. Optimal thermal management is achieved by effectively coupling the thermal pad to a heatsink or designing the PCB with an effective thermal layer to disperse heat from the MOSFET.

4. Maximizing the Performance of the CSD18534Q5A: To realize the full potential of the CSD18534Q5A, it is crucial to mitigate parasitic elements within the circuit, particularly around the gate and drain areas. Selecting appropriate gate resistors can fine-tune the switching behavior, curtailing unwanted oscillations. Strategic power path layout and employing high-quality decoupling components can further amplify the device's operational efficiency and reliability.

5. Design Perspectives for Employing the CSD18534Q5A: Integrating the CSD18534Q5A into a design necessitates a thoughtful PCB layout to minimize loop resistance and inductance, key factors for maintaining high efficiency. The placement of the MOSFET in relation to other components should prioritize thermal management and integration convenience, especially in compact designs. Choosing external components that complement the MOSFET's specifications can lead to a harmonious and efficient design.

6. Utilization Spectrum of the CSD18534Q5A: The robust and efficient nature of the CSD18534Q5A renders it suitable for a wide range of applications, including sophisticated power supplies, motor control systems, and efficient DC-DC converters. Its capability to handle high currents with minimal losses makes it a preferred choice for engineers focused on optimizing power management within electronic systems.

To sum up, the CSD18534Q5A, part of the NexFET™ MOSFET series, stands out as a premier solution for power management challenges in various electronic applications. Its low on-resistance, rapid switching capabilities, and outstanding thermal management position it as an ideal choice for designs requiring high efficiency and reliability. A deliberate approach to the device's integration, emphasizing pin arrangement, thermal dissipation, and circuit layout, is vital to exploit the CSD18534Q5A's full capabilities, thereby boosting the performance and durability of the electronic system it powers.
