Infineon Technologies BSS169H6327XTSA1

Part No.:: BSS169H6327XTSA1

Manufacturer:: Infineon Technologies

Package:: PG-SOT23

Datasheet:: BSS169H6327XTSA1.pdf

Description:: MOSFET N-CH 100V 170MA SOT23-3

In Stock:: 92729

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BSS169H6327XTSA1 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
SIPMOS®
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
100 V
Current-ContinuousDrain(Id)@25°C:
170mA (Ta)
DriveVoltage(MaxRdsOnMinRdsOn):
0V, 10V
RdsOn(Max)@IdVgs:
6Ohm @ 170mA, 10V
Vgs(th)(Max)@Id:
1.8V @ 50µA
GateCharge(Qg)(Max)@Vgs:
2.8 nC @ 7 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
68 pF @ 25 V
FETFeature:
Depletion Mode
PowerDissipation(Max):
360mW (Ta)
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
