Nexperia USA Inc. BSH103BKR

Part No.:: BSH103BKR

Manufacturer:: Nexperia USA Inc.

Package:: TO-236AB

Datasheet:: BSH103BKR.pdf

Description:: BSH103BK - 30 V, N-CHANNEL TRENC

In Stock:: 3290

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BSH103BKR Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
TrenchMOS™
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
30 V
Current-ContinuousDrain(Id)@25°C:
1A (Ta)
DriveVoltage(MaxRdsOnMinRdsOn):
1.8V, 4.5V
RdsOn(Max)@IdVgs:
270mOhm @ 1A, 4.5V
Vgs(th)(Max)@Id:
1.25V @ 250µA
GateCharge(Qg)(Max)@Vgs:
1.2 nC @ 4.5 V
Vgs(Max):
±12V
InputCapacitance(Ciss)(Max)@Vds:
79.3 pF @ 15 V
FETFeature:
-
PowerDissipation(Max):
330mW (Ta), 2.1W (Tc)
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
