Infineon Technologies BSC320N20NS3GATMA1

Part No.:: BSC320N20NS3GATMA1

Manufacturer:: Infineon Technologies

Package:: PG-TDSON-8-1

Datasheet:: BSC320N20NS3GATMA1.pdf

Description:: MOSFET N-CH 200V 36A TDSON-8

In Stock:: 2132

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BSC320N20NS3GATMA1 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
OptiMOS™
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
200 V
Current-ContinuousDrain(Id)@25°C:
36A (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
10V
RdsOn(Max)@IdVgs:
32mOhm @ 36A, 10V
Vgs(th)(Max)@Id:
4V @ 90µA
GateCharge(Qg)(Max)@Vgs:
29 nC @ 10 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
2350 pF @ 100 V
FETFeature:
-
PowerDissipation(Max):
125W (Tc)
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
