Infineon Technologies BSC028N06NSTATMA1

Part No.:: BSC028N06NSTATMA1

Manufacturer:: Infineon Technologies

Package:: PG-TDSON-8-7

Datasheet:: BSC028N06NSTATMA1.pdf

Description:: MOSFET N-CH 60V 24A/100A TDSON

In Stock:: 7543

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BSC028N06NSTATMA1 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
OptiMOS™
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
60 V
Current-ContinuousDrain(Id)@25°C:
24A (Ta), 100A (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
6V, 10V
RdsOn(Max)@IdVgs:
2.8mOhm @ 50A, 10V
Vgs(th)(Max)@Id:
3.3V @ 50µA
GateCharge(Qg)(Max)@Vgs:
49 nC @ 10 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
3375 pF @ 30 V
FETFeature:
-
PowerDissipation(Max):
3W (Ta), 100W (Tc)
OperatingTemperature:
-55°C ~ 175°C (TJ)
MountingType:
Surface Mount
