Name: AO4468
Brand: Alpha & Omega Semiconductor Inc.
SKU: AO4468
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Alpha & Omega Semiconductor Inc. AO4468

Part No.:: AO4468

Manufacturer:: Alpha & Omega Semiconductor Inc.

Package:: 8-SOIC

Datasheet:: AO4468.pdf

Description:: MOSFET N-CH 30V 10.5A 8SOIC

In Stock:: 1540

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AO4468 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Not For New Designs
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
30 V
Current-ContinuousDrain(Id)@25°C:
10.5A (Ta)
DriveVoltage(MaxRdsOnMinRdsOn):
4.5V, 10V
RdsOn(Max)@IdVgs:
14mOhm @ 11.6A, 10V
Vgs(th)(Max)@Id:
3V @ 250µA
GateCharge(Qg)(Max)@Vgs:
24 nC @ 10 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
1200 pF @ 15 V
FETFeature:
-
PowerDissipation(Max):
3.1W (Ta)
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount

AO4468 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including AO4468 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for AO4468 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

AO4468 information

Views：

AO4468 Typical application Circuitry

AO4468

The AO4468 is a high-performance, N-channel MOSFET from Alpha & Omega Semiconductor, designed for fast switching applications. It is widely used in power management technology, especially in DC-DC converters, power supplies, and load switch applications. Its key features include low on-resistance (R_DS(on)), high current capability, and a compact SOP-8 package, making it suitable for high efficiency, space-constrained applications.

Application Scenarios and Parameter Features

The AO4468 is characterized by a 30V drain-source voltage (V_DS), a continuous drain current (I_D) of up to 20A, and a low on-resistance of 8.5 mΩ at V_GS = 10V. These specifications make it highly suitable for applications requiring efficient power handling and switching, such as in portable electronics, computing systems (for CPU and GPU power management), and in motor control circuits for drones or small electric vehicles.

One particular use case for it is in synchronous buck converters, a kind of DC-DC converter that is frequently used in portable devices to step down voltage with excellent efficiency.

Specific Circuit Connection

Incorporating the AO4468 into a synchronous buck converter involves detailed planning to ensure efficient power conversion. Below are detailed circuit connections and considerations:

1. Power Switch Connection: First, integrate the AO4468 as the low-side switch in the synchronous buck converter. Connect the Drain (D, pin 5-8) to the system ground. This provides the returning current's path when the low-side switch is in the on position.

2. Control Signal Connection: The Gate (G, pin 4) should be connected to the output of the PWM controller. A gate resistor (Rg) might be needed between the PWM controller and the Gate of the AO4468 to control the switching speed and minimize ringing.

3. Source Connection: The load's negative terminal is connected to the Source (S, pins 1-3). This configuration allows the AO4468 to complete the circuit path when turned on, allowing current to flow through the load.

4. Bootstrap Diode and Capacitor: For high-side drive in applications where the AO4468 is used, a bootstrap diode and capacitor are required to provide the gate drive voltage. However, in a low-side application like a synchronous buck converter, these are not required for the AO4468 itself but are relevant for the high-side MOSFET.

Design-Related Issues

When constructing the circuit, it is important to consider the following:

- Voltage of Gate Drive: To fully switch on the MOSFET and reduce conduction losses, make sure the gate drive voltage is within the recommended range on the AO4468.

- Thermal Management: The AO4468 can handle significant current, but it also generates heat. Make that there is enough ventilation or heat sinking to keep the MOSFET within its working temperature range.

- Parasitic Inductance: Minimize parasitic inductance in the PCB layout to reduce voltage spikes at the drain of the AO4468 during switching. Short, wide traces and proper grounding are crucial.

- Protection: Consider implementing over-current and over-temperature protection mechanisms to safeguard the AO4468 and the overall circuit from abnormal conditions.

By carefully considering these design principles and ensuring proper connections to the AO4468, developers can effectively integrate this N-channel MOSFET into synchronous buck converters or similar power management applications, achieving high efficiency and performance in compact, demanding environments.
