Alpha & Omega Semiconductor Inc. AO3401L_101

Part No.:: AO3401L_101

Manufacturer:: Alpha & Omega Semiconductor Inc.

Package:: SOT-23-3

Datasheet:

Description:: MOSFET P-CH 30V 4.2A SOT23-3

In Stock:: 3815

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AO3401L_101 Specifications

Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Obsolete
FETType:
P-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
30 V
Current-ContinuousDrain(Id)@25°C:
4.2A (Ta)
DriveVoltage(MaxRdsOnMinRdsOn):
2.5V, 10V
RdsOn(Max)@IdVgs:
50mOhm @ 4.2A, 10V
Vgs(th)(Max)@Id:
1.3V @ 250µA
GateCharge(Qg)(Max)@Vgs:
9.4 nC @ 4.5 V
Vgs(Max):
±12V
InputCapacitance(Ciss)(Max)@Vds:
954 pF @ 15 V
FETFeature:
-
PowerDissipation(Max):
1.4W (Ta)
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount

AO3401L_101 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including AO3401L_101 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for AO3401L_101 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

AO3401L_101 information

Views：

AO3401L_101 Typical application Circuitry

AO3401L_101

The AO3401L_101 is a P-Channel MOSFET known for its efficiency in power management applications. This variant of the AO3401 series is particularly suited for high-side switching in portable and low-voltage applications due to its low on-resistance and small form factor.

Application Scenarios

Portable Device Battery Management: In portable electronic devices, the AO3401L_101 is commonly used for managing battery power, controlling the distribution and regulation of power within the device.

Parameter Features

- Low On-Resistance: Reduces power loss, enhancing overall efficiency in high-current applications.

- Small Package Size: Ideal for compact electronic devices where space is limited.

- High-Side Switching: Suitable for applications requiring high-side load switching.

Circuit Connection Example

In a portable device's battery management circuit, the AO3401L_101 can be integrated as follows:

1. Source Pin Connection: Connect the source pin of the AO3401L_101 to the positive voltage supply. In P-Channel MOSFETs, the source is connected to the higher potential.

2. Drain Pin to Load: Attach the drain pin to the load, such as a part of the device's circuitry that requires controlled power (e.g., a display screen or sensor).

3. Gate Pin for Control: Link the gate pin to a control signal, usually from a microcontroller. The signal will turn the MOSFET on or off, thus controlling the power to the load.

4. Pull-Up Resistor on Gate: Include a pull-up resistor between the gate and the source. This ensures the MOSFET stays off when no control signal is present.

Design Considerations

When designing a circuit with the AO3401L_101, consider the following:

- Heat Management: Implement proper thermal management as the AO3401L_101 can generate heat, particularly under high current conditions.

- Gate Drive Voltage: Ensure the gate drive voltage is suitable for turning the MOSFET on and off efficiently.

- Load Characteristics: Understand the load to ensure the MOSFET can handle the required current without exceeding its maximum specifications.

- Protection Mechanisms: Include protective elements like current limiters or fuses to safeguard against overcurrent and short-circuit conditions.

In summary, the AO3401L_101 plays a vital role in portable device battery management systems, offering efficient high-side load switching. Its low on-resistance and compact size make it particularly beneficial for power distribution and regulation in space-constrained portable electronics.
