Alpha & Omega Semiconductor Inc. AO3401L

Part No.:: AO3401L

Manufacturer:: Alpha & Omega Semiconductor Inc.

Package:: SOT-23-3

Datasheet:

Description:: MOSFET P-CH 30V 4.2A SOT23-3

In Stock:: 3940

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AO3401L Specifications

Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Obsolete
FETType:
P-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
30 V
Current-ContinuousDrain(Id)@25°C:
4.2A (Ta)
DriveVoltage(MaxRdsOnMinRdsOn):
2.5V, 10V
RdsOn(Max)@IdVgs:
50mOhm @ 4.2A, 10V
Vgs(th)(Max)@Id:
1.3V @ 250µA
GateCharge(Qg)(Max)@Vgs:
9.4 nC @ 4.5 V
Vgs(Max):
±12V
InputCapacitance(Ciss)(Max)@Vds:
954 pF @ 15 V
FETFeature:
-
PowerDissipation(Max):
1.4W (Ta)
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount

AO3401L this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including AO3401L price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for AO3401L to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

AO3401L information

Views：

AO3401L Typical application Circuitry

AO3401L

The AO3401L is a P-Channel MOSFET that is widely used in electronic circuits for its efficient power management capabilities. It is especially favored in applications requiring low on-resistance and high-speed switching, such as power distribution systems, load switching, and as a switching element in various power management modules.

Application Scenarios

Power Distribution in Consumer Electronics: The AO3401L is commonly used in the power distribution systems of consumer electronics, where it controls the power supply to different components efficiently and reliably.

Parameter Features

- Low On-Resistance: This characteristic is crucial for reducing power loss and improving efficiency in high-current applications.

- High-Speed Switching: The AO3401L's ability to switch rapidly makes it suitable for applications that demand quick response times.

- Compact Size: Ideal for space-constrained applications, like portable electronic devices.

Circuit Connection Example

In a power distribution system of a consumer electronic device, the AO3401L can be integrated as follows:

1. Source Pin Connection: Connect the source pin of the AO3401L to the positive power supply. In P-Channel MOSFETs, the source is typically connected to the higher voltage.

2. Drain Pin to Load: Attach the drain pin to the load that requires control, such as a part of the device's internal circuitry needing regulated power.

3. Gate Pin for Control: Link the gate pin to a control signal, usually provided by a microcontroller or a power management IC. This signal controls the MOSFET's switching, thereby managing power delivery to the load.

4. Pull-Up Resistor on Gate: A pull-up resistor should be placed between the source and the gate. This ensures the MOSFET stays off when the control signal is not active.

Design Considerations

A circuit designed with the AO3401L should take into account a number of factors:

- Thermal Management: The AO3401L can produce heat, particularly when operating at high currents, thus adequate heat dissipation is crucial.

- Gate Drive Voltage: It's important to ensure the gate drive voltage is sufficient to fully activate the MOSFET.

- Load Specifications: Evaluate the load to confirm the MOSFET can handle the expected current and power levels.

- Protective Measures: Implement protections against overcurrent, voltage spikes, and reverse polarity to safeguard the MOSFET and other circuit components.

In summary, the AO3401L is a key component in the power distribution systems of consumer electronics, offering efficient and reliable control of power supply with its low on-resistance and high-speed switching capabilities. These features are vital for the effective and energy-efficient operation of modern electronic devices.
