Alpha & Omega Semiconductor Inc. AO3401AL_101

Part No.:: AO3401AL_101

Manufacturer:: Alpha & Omega Semiconductor Inc.

Package:: SOT-23-3

Datasheet:

Description:: MOSFET P-CH 30V 4.3A SOT23-3

In Stock:: 3962

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AO3401AL_101 Specifications

Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Obsolete
FETType:
P-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
30 V
Current-ContinuousDrain(Id)@25°C:
4.3A (Ta)
DriveVoltage(MaxRdsOnMinRdsOn):
2.5V, 10V
RdsOn(Max)@IdVgs:
44mOhm @ 4.3A, 10V
Vgs(th)(Max)@Id:
1.3V @ 250µA
GateCharge(Qg)(Max)@Vgs:
12.2 nC @ 4.5 V
Vgs(Max):
±12V
InputCapacitance(Ciss)(Max)@Vds:
1200 pF @ 15 V
FETFeature:
-
PowerDissipation(Max):
1.4W (Ta)
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
