MDD AO3400-5.8A

Part No.:: AO3400-5.8A

Manufacturer:: MDD

Package:: SOT-23

Datasheet:: AO3400-5.8A.pdf

Description:: MOSFET SOT-23 N Channel 30V

In Stock:: 249000

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AO3400-5.8A Specifications

Packaging:
Tape & Reel (TR)
Series:
SOT-23
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
30 V
Current-ContinuousDrain(Id)@25°C:
5.8A (Ta)
DriveVoltage(MaxRdsOnMinRdsOn):
3.3V, 4.5V
RdsOn(Max)@IdVgs:
32mOhm @ 5.8A, 10V
Vgs(th)(Max)@Id:
1.2V @ 250µA
GateCharge(Qg)(Max)@Vgs:
10.5 nC @ 15 V
Vgs(Max):
±12V
InputCapacitance(Ciss)(Max)@Vds:
630 pF @ 15 V
FETFeature:
-
PowerDissipation(Max):
1.5W (Ta)
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount

AO3400-5.8A this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including AO3400-5.8A price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for AO3400-5.8A to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

AO3400-5.8A information

Views：

AO3400-5.8A Typical application Circuitry

AO3400-5.8A

An effective N-Channel MOSFET for power management and switching is the AO3400-5.8A. It is particularly known for its low on-resistance and high current handling capabilities, making it suitable for a wide range of applications including power supply circuits, load switching, and as a part of the power management system in various electronic devices.

Application Scenarios

Power Supply Circuits: In power supply units, the AO3400-5.8A is commonly used for switching in power conversion stages, such as in DC-DC converters, due to its efficiency and ability to handle significant current.

Parameter Features

- Low On-Resistance: Minimizes power losses, enhancing overall efficiency.

- High Current Capability: Can handle up to 5.8A, suitable for high-current applications.

- Fast Switching Speed: Suitable for applications requiring quick switching.

Circuit Connection Example

In a DC-DC converter within a power supply unit, the AO3400-5.8A can be integrated as follows:

1. Source Pin Connection: Connect the Source pin of the AO3400-5.8A to the ground. This is crucial as the Source pin serves as the reference point for the MOSFET.

2. Drain Pin to Load: Attach the Drain pin to the load component of the DC-DC converter circuit, such as the inductor or the input of the next stage. The AO3400-5.8A controls the flow of power to this component.

3. Gate Pin Control: Connect the Gate pin to a PWM (Pulse Width Modulation) controller. The PWM signal regulates the on/off state of the MOSFET, controlling power flow in the converter.

4. Gate Resistor: Place a resistor between the Gate pin and the PWM controller to limit the inrush current and stabilize the operation of the MOSFET.

Design Considerations

When designing a circuit with the AO3400-5.8A, consider the following:

- Thermal Management: Implement adequate cooling as the AO3400-5.8A can generate heat, especially when switching high currents.

- Gate Drive Voltage: Ensure that the gate drive voltage is adequate to fully turn on the MOSFET for optimal efficiency.

- Load Requirements: Be aware of the load characteristics to ensure the MOSFET can handle the required current and power levels.

- Protection Against Voltage Spikes: Include protective components to safeguard against voltage spikes and other harmful conditions.

In summary, the AO3400-5.8A is a critical component in power supply circuits, particularly in DC-DC converters, where its low on-resistance and high current handling capability are essential for efficient and reliable power conversion.
