Micro Commercial Co 2SK3018-TP

Part No.:: 2SK3018-TP

Manufacturer:: Micro Commercial Co

Package:: SOT-323

Datasheet:: 2SK3018-TP.pdf

Description:: MOSFET N-CH 30V 100MA SOT323

In Stock:: 3214

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

2SK3018-TP Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
30 V
Current-ContinuousDrain(Id)@25°C:
100mA (Ta)
DriveVoltage(MaxRdsOnMinRdsOn):
2.5V
RdsOn(Max)@IdVgs:
8Ohm @ 10mA, 4V
Vgs(th)(Max)@Id:
1.5V @ 100µA
GateCharge(Qg)(Max)@Vgs:
-
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
13 pF @ 5 V
FETFeature:
-
PowerDissipation(Max):
200mW (Ta)
OperatingTemperature:
-55°C ~ 150°C
MountingType:
Surface Mount
