Vishay Siliconix SI7997DP-T1-GE3

Part No.:: SI7997DP-T1-GE3

Manufacturer:: Vishay Siliconix

Package:: PowerPAK® SO-8 Dual

Datasheet:: SI7997DP-T1-GE3.pdf

Description:: MOSFET 2P-CH 30V 60A PPAK SO-8

In Stock:: 2106

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SI7997DP-T1-GE3 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
TrenchFET®
ProductStatus:
Active
FETType:
2 P-Channel (Dual)
FETFeature:
Standard
DraintoSourceVoltage(Vdss):
30V
Current-ContinuousDrain(Id)@25°C:
60A
RdsOn(Max)@IdVgs:
5.5mOhm @ 20A, 10V
Vgs(th)(Max)@Id:
2.2V @ 250µA
GateCharge(Qg)(Max)@Vgs:
160nC @ 10V
InputCapacitance(Ciss)(Max)@Vds:
6200pF @ 15V
Power-Max:
46W
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
