ON Semiconductor NTGD4167CT1G

Part No.:: NTGD4167CT1G

Manufacturer:: ON Semiconductor

Package:: SOT-23-6 Thin, TSOT-23-6

Datasheet:: NTGD4167CT1G.pdf

Description:: MOSFET N/P-CH 30V 2.6/1.9A 6TSOP

In Stock:: 3979

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

NTGD4167CT1G Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
FETType:
N and P-Channel
FETFeature:
Logic Level Gate
DraintoSourceVoltage(Vdss):
30V
Current-ContinuousDrain(Id)@25°C:
2.6A, 1.9A
RdsOn(Max)@IdVgs:
90mOhm @ 2.6A, 4.5V
Vgs(th)(Max)@Id:
1.5V @ 250µA
GateCharge(Qg)(Max)@Vgs:
5.5nC @ 4.5V
InputCapacitance(Ciss)(Max)@Vds:
295pF @ 15V
Power-Max:
900mW
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
