Nexperia USA Inc. BSS138BKS,115

Part No.:: BSS138BKS,115

Manufacturer:: Nexperia USA Inc.

Package:: 6-TSSOP, SC-88, SOT-363

Datasheet:: BSS138BKS,115.pdf

Description:: MOSFET 2N-CH 60V 0.32A 6TSSOP

In Stock:: 2522

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BSS138BKS,115 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Automotive, AEC-Q101, TrenchMOS™
ProductStatus:
Active
FETType:
2 N-Channel (Dual)
FETFeature:
Logic Level Gate
DraintoSourceVoltage(Vdss):
60V
Current-ContinuousDrain(Id)@25°C:
320mA
RdsOn(Max)@IdVgs:
1.6Ohm @ 320mA, 10V
Vgs(th)(Max)@Id:
1.6V @ 250µA
GateCharge(Qg)(Max)@Vgs:
0.7nC @ 4.5V
InputCapacitance(Ciss)(Max)@Vds:
56pF @ 10V
Power-Max:
445mW
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
