Vishay Siliconix SI4816BDY-T1-E3

Part No.:: SI4816BDY-T1-E3

Manufacturer:: Vishay Siliconix

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: SI4816BDY-T1-E3.pdf

Description:: MOSFET 2N-CH 30V 5.8A 8-SOIC

In Stock:: 3583

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SI4816BDY-T1-E3 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
LITTLE FOOT®
ProductStatus:
Active
FETType:
2 N-Channel (Half Bridge)
FETFeature:
Logic Level Gate
DraintoSourceVoltage(Vdss):
30V
Current-ContinuousDrain(Id)@25°C:
5.8A, 8.2A
RdsOn(Max)@IdVgs:
18.5mOhm @ 6.8A, 10V
Vgs(th)(Max)@Id:
3V @ 250µA
GateCharge(Qg)(Max)@Vgs:
10nC @ 5V
InputCapacitance(Ciss)(Max)@Vds:
-
Power-Max:
1W, 1.25W
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
