ON Semiconductor NVMFD5C650NLT1G

Part No.:: NVMFD5C650NLT1G

Manufacturer:: ON Semiconductor

Package:: 8-PowerTDFN

Datasheet:: NVMFD5C650NLT1G.pdf

Description:: MOSFET 2N-CH 60V 111A S08FL

In Stock:: 2333

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

NVMFD5C650NLT1G Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Automotive, AEC-Q101
ProductStatus:
Active
FETType:
2 N-Channel (Dual)
FETFeature:
Standard
DraintoSourceVoltage(Vdss):
60V
Current-ContinuousDrain(Id)@25°C:
21A (Ta), 111A (Tc)
RdsOn(Max)@IdVgs:
4.2mOhm @ 20A, 10V
Vgs(th)(Max)@Id:
2.2V @ 98µA
GateCharge(Qg)(Max)@Vgs:
16nC @ 4.5V
InputCapacitance(Ciss)(Max)@Vds:
2546pF @ 25V
Power-Max:
3.5W (Ta), 125W (Tc)
OperatingTemperature:
-55°C ~ 175°C (TJ)
MountingType:
Surface Mount
