ON Semiconductor NVMFD5C466NLT1G

Part No.:: NVMFD5C466NLT1G

Manufacturer:: ON Semiconductor

Package:: 8-PowerTDFN

Datasheet:: NVMFD5C466NLT1G.pdf

Description:: MOSFET 2N-CH 40V 52A S08FL

In Stock:: 2045

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

NVMFD5C466NLT1G Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Automotive, AEC-Q101
ProductStatus:
Active
FETType:
2 N-Channel (Dual)
FETFeature:
Standard
DraintoSourceVoltage(Vdss):
40V
Current-ContinuousDrain(Id)@25°C:
14A (Ta), 52A (Tc)
RdsOn(Max)@IdVgs:
7.4mOhm @ 10A, 10V
Vgs(th)(Max)@Id:
2.2V @ 30µA
GateCharge(Qg)(Max)@Vgs:
7nC @ 4.5V
InputCapacitance(Ciss)(Max)@Vds:
997pF @ 25V
Power-Max:
3W (Ta), 40W (Tc)
OperatingTemperature:
-55°C ~ 175°C (TJ)
MountingType:
Surface Mount

NVMFD5C466NLT1G this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including NVMFD5C466NLT1G price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for NVMFD5C466NLT1G to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

NVMFD5C466NLT1G information

Views：

NVMFD5C466NLT1G Typical application Circuitry

The NVMFD5C466NLT1G is a dual N-Channel Power MOSFET device developed by ON Semiconductor. Its primary function is to facilitate efficient power management in various applications.

The NVMFD5C466NLT1G is applied in various domains. Power supply circuits, load switching, DC-DC converters, and motor control are some of the common application scenarios.

Key features of the NVMFD5C466NLT1G include:

- Drain-Source Voltage: 40V

- Continuous Drain Current: 39A (Tc=25°C)

- Maximum Power Dissipation: 40W (Tc=25°C)

- Faster switching times with Low Gate Charge (Qg)

- Low RDS(on) to reduce losses in the on-state

- These attributes make it an efficient device for high-frequency switching applications.

Consider using the NVMFD5C466NLT1G in a motor control application:

1. Source Pins (Pins 5, 6, 7, 8): These pins are commonly connected to the circuit ground. In our motor control application, these pins would be attached to the ground of the power supply.

2. Gate Pins (Pins 3 and 4): These are the control pins for the MOSFETs. These pins receive a pulse-width modulated (PWM) signal from a controller circuit. This PWM signal controls the speed of the motor by modulating the MOSFETs on and off.

3. Drain Pins (Pins 1 and 2): These pins connect to the load or the higher voltage level. These pins would be connected to the motor terminals in this application.

When working with the NVMFD5C466NLT1G, these considerations are necessary:

- Heat Management: The device may handle high power, so effective thermal management strategies (e.g., heatsinks, fans) should be considered to prevent overheating.

- Protection: The inclusion of protective measures, such as flyback diodes, may be necessary to guard against high voltage or current spikes.

- Drive Circuitry: A suitable gate driving circuit is required to ensure optimal and safe operation of the NVMFD5C466NLT1G.

- PCB Layout: The layout of the PCB should be designed to minimize stray inductances and resistances and ensure sufficient heat dissipation.

The NVMFD5C466NLT1G is thus a highly versatile dual N-Channel Power MOSFET, making it suitable for various power management and motor control applications.
