ON Semiconductor FDMA6023PZT

Part No.:: FDMA6023PZT

Manufacturer:: ON Semiconductor

Package:: 6-UDFN Exposed Pad

Datasheet:: FDMA6023PZT.pdf

Description:: MOSFET 2P-CH 20V 3.6A 6MICROFET

In Stock:: 2066

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

FDMA6023PZT Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
PowerTrench®
ProductStatus:
Last Time Buy
FETType:
2 P-Channel (Dual)
FETFeature:
Logic Level Gate
DraintoSourceVoltage(Vdss):
20V
Current-ContinuousDrain(Id)@25°C:
3.6A
RdsOn(Max)@IdVgs:
60mOhm @ 3.6A, 4.5V
Vgs(th)(Max)@Id:
1.5V @ 250µA
GateCharge(Qg)(Max)@Vgs:
17nC @ 4.5V
InputCapacitance(Ciss)(Max)@Vds:
885pF @ 10V
Power-Max:
700mW
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
